Zigbee2MQTT and Unsupported Devices: How to Add Your Own

Zigbee2MQTT is an excellent open-source project that allows you to create a Zigbee gateway and integrate various devices into your smart home ecosystem. While many devices are supported out of the box, there may be instances where a specific device isn't officially recognized. In this guide, we'll walk you through the process of adding support for the Gledopto GL-LB-001P RGB+CCT LED bar to Zigbee2MQTT using zigbee-herdsman-converters.

Check Device Compatibility

Before proceeding, check if your device is already supported in the Zigbee2MQTT development branch by searching for your Zigbee model in the project's repository.

1. Pairing the Device with Zigbee2MQTT

The first step is to pair your device with Zigbee2MQTT:

Put the GL-LB-001P into pairing mode (usually done by performing a factory reset).
Ensure that joining is enabled in your Zigbee2MQTT configuration.
Once paired, you will see a log message indicating that the device has been detected but is not yet supported:

Zigbee2MQTT:info 2019-11-09T12:19:56: Successfully interviewed '0x00158d0001dc126a', device has successfully been paired.
Zigbee2MQTT:warn 2019-11-09T12:19:56: Device '0x00158d0001dc126a' with Zigbee model 'lumi.sens' and manufacturer name 'some_name' is NOT supported.

2. Adding Support for Your Device

To add support, create an external converter file named GLEDOPTO.js inside your Zigbee2MQTT folder. This file will define how Zigbee2MQTT should communicate with your device.

Sample `GLEDOPTO.js` Converter

const fz = require('zigbee-herdsman-converters/converters/fromZigbee');
const tz = require('zigbee-herdsman-converters/converters/toZigbee');
const extend = require('zigbee-herdsman-converters/lib/extend');
const exposes = require('zigbee-herdsman-converters/lib/exposes');
const e = exposes.presets;

const light_onoff_brightness_colortemp_color = (options = {}) => ({
    ...extend.light_onoff_brightness_colortemp_color({
        disablePowerOnBehavior: true,
        supportsHueAndSaturation: true,
        ...options,
    }),
    toZigbee: [
        tz.gledopto_light_onoff_brightness,
        tz.gledopto_light_color_colortemp,
    ],
});

const definition = {
    zigbeeModel: ['GL-LB-001P'],
    model: 'GL-LB-001P',
    vendor: 'Gledopto',
    description: 'Zigbee USB LED bar RGB+CCT (pro)',
    extend: light_onoff_brightness_colortemp_color({
        colorTempRange: [158, 495],
        disablePowerOnBehavior: false,
    }),
};

module.exports = definition;

3. Updating Your Zigbee2MQTT Configuration

After creating the GLEDOPTO.js file, update your Zigbee2MQTT configuration:

Restart Zigbee2MQTT for the new converter to be recognized.
- If using Home Assistant:
  - Go to Supervisor > Add-ons > Zigbee2MQTT.
  - Click Restart.
- If running Zigbee2MQTT manually, restart the service using:
```
  systemctl restart zigbee2mqtt
```

4. Pair and Control Your Gledopto GL-LB-001P

Once Zigbee2MQTT restarts, reattempt pairing. Your Gledopto GL-LB-001P should now be recognized and fully controllable through Zigbee2MQTT.

Conclusion

Adding support for unsupported Zigbee devices like the Gledopto GL-LB-001P might seem complex, but with the right approach, you can expand your smart home capabilities. By following this guide, you've successfully integrated your RGB+CCT LED bar into Zigbee2MQTT.

Happy tinkering!
